Description
Low-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to our popular Harken Big Boat blocks, these small, compact blocks have very high working loads for safe, easy trimming.
| Sheave Ø (mm) | 40 mm |
| Sheave Ø (in) | 1 9/16 in |
| Length (mm) | 94 mm |
| Length (in) | 3 11/16 in |
| Weight (g) | 232 g |
| Weight (oz) | 8.2 oz |
| Maximum line Ø (mm) | 6 mm |
| Maximum line Ø (in) | 1/4 in |
| Maximum working load (kg) | 340 kg |
| Maximum working load (lb) | 750 lb |
| Breaking load (lb) | 1500 lb |
| Breaking load (kg) | 680 kg |
| Shackle pin Ø (mm) | 5 mm |
| Shackle pin Ø (in) | 3/16 in |
