Description
4mm Shallow Bow Shackle
Forged stainless steel shackles are polished to a high luster and are stamped with the screw pin diameter. Bow shackles are best for multidirectional loads. Shallow bow shackles are proportionally wider for their length than regular bow shackles.
| Weight (g) | 8.5 g |
| Weight (oz) | 0.3 oz |
| Maximum working load (kg) | 367 kg |
| Maximum working load (lb) | 810 lb |
| Breaking load (lb) | 1620 lb |
| Breaking load (kg) | 735 kg |
| A (mm) | 16 mm |
| A (in) | 5/8 in |
| B (mm) | 8 mm |
| B (in) | 5/16 in |
| Shackle pin Ø (mm) | 4 mm |
| Shackle pin Ø (in) | 5/32 in |
| C (mm) | 11 mm |
| C (in) | 7/16 in |
